| lifting capacity | 4T |
| lifting height | 1700mm |
| min. height | 220mm |
| table length | 4500mm |
| total length | 4860mm |
| total width | 3340mm |
| width between columns | 2990mm |
| single lane width | 550mm |
| lane spacing | 950mm |
| column height | 2000mm |
| Secondary lifting height | 320-480mm |
| motor power | 2.2kw |
| voltage | 380v/220v |
| unlock mode | manual unlock |
1.Electric, manual and unlocking are adopted.
2.The hydraulic power unit is equipped with throttling device, and the lowering speed can be adjusted at any time.
3.Driven by hydraulic cylinder and steel wire rope, the lifting is stable and quiet.
4.The steel wire rope control safety lock is set, which has the fuction of protecting the steel wire rope from breakage, making the operation safer.
5.It adopts electric linkage lock and eight point locking for convenient operation.
6.It can be locked at the required height to operate safely and reliably.
7.The runway spacing is adjustable and suitable for vehicles with differentctrack widths.
8.It is equipped with a secondary lifting trolley, which can be manually,pneumatically or hydraulically lifted.
