Rim diameter 10 “-24”
The maximum wheel weight is 65 kg
Maximum wheel diameter 1000mm
Rim width 1,5 “-20”
balancing precision ±1g
power of motor 0.25kW
Power supply 100/230V 1ph
Measuring speed 200rpm
Equilibrium period 10s
Secondary disassembly ≤5g
Machine size 1250x1050x1050 mm
Packing size 930x710x1160 mm
Net weight 107 kg
Gross weight 137 kg
40-foot container quantity 68 sets
Computer tire dynamic balancing machine with completely independent intellectual property rights
This product includes tire dynamic balance/static balance, various aluminum alloy balance modes and motorcycle tire balance modes.
Allow users to customize and edit the most suitable balance operation habit settings intuitively according to their needs, which can greatly improve work efficiency. It has the functions of shield sub-control, definition of unit system, selection of minimum unbalance and so on.
With a variety of creative tire data input methods, it is convenient and fast to use tire rotation, and data adjustment and input can also be realized.
Self-calibration is simple and easy to operate, and it can quickly restore the accuracy of machines that have not been used for a long time and those that have lost their accuracy.
Optional motorcycle fixture, with motorcycle balance mode
The lead block cover with injection molding technology is beautiful and durable, which improves the flexibility of the product, and each piece ensures the same size and is convenient to replace.
The IMD die is scratch-resistant, corrosion-resistant and long in service life. The strength of the key is high, and it will not be damaged after 500 thousand presses. When the temperature is-10 50, the mask will not delaminate, bubble or open.
